PX-55192-Z10C 10GBASE-ZR 1550nm 100Km XFP Optical Transceiver

Features

XFP MSA Rev 4.5 Compliant

Data rate from 9.95Gbps to 11.3Gbps

Cooled EML with isolator

APD receiver

Link length up to 100km (with amplifier)

Low Power Dissipation 3.5W Maximum

XFI and lineside loopback Mode Supported

-5ºC to 70ºC Operating Case Temperature

Diagnostic Performance Monitoring of module temperature,Supply Voltages, laser bias current,transmit optical power, and receive optical power

RoHS compliant (lead free)

Applications

SONET OC-192&SDH STM 64

Ethernet (10GBASE and 10GBASE with FEC)

Fiber Channel (10G and 10G with FEC)

Description

PRONETS 100km XFP Transceiver is designed for 10G SDH/SONET and 10G Fiber Channel applications.

The transmitter section incorporates a colded EML laser, and the receiver section consists of a APD photodiode integrated with a TIA, Integrated low power dual CDR with Electronic Dispersion Compensation
