PPP-316G-02x Multi Rate 1.25-6.25 Gbps LTE 1310nm 2Km SFP+ Optical Transceiver
5.0
like
Specification Download:
/uploads/hongyuan.weyes.com.cn/addon/PPP-316G-02x.pdf
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Features
Support Multi Rate 1.25-6.25 Gbps
Hot Pluggable SFP+ footprint
1310nm FP transmitter, PIN photo-detector
Transmission distance up to 2km on 9/125 μm SMF
Digital Status monitoring Interface
Duplex LC connector
RoHS compliant and Lead Free
Metal enclosure for lower EMI
Single 3.3V power supply
Power dissipation <1W
Compliant with FC-PI-4 800-Mx-SN-I, SFF-8431 , SFF-8432 and SFF-8472
Operating case temperature:
Standard : -5 to +70℃
Industrial : -40 to +85℃
Applications
High-speed storage area networks
Computer cluster cross-connect
Custom high-speed data pipes
LTE optical repeater application
Description
PPP-316G-02x is a high performance, cost effective modules, which is supporting Multi Rate
1.25-6.25Gbps, and transmission distance up to 2km on SM fiber. The transceiver consists of two
sections: The transmitter section incorporates a 1310nm FP driver and re-timer. The receiver
section consists of a PIN photodiode integrated with a transimpedance preamplifier (TIA). The
module is hot pluggable into the 20-pin connector. The high-speed electrical interface is base on low
voltage logic, with nominal 100 Ohms differential impedance and AC coupled in the module.
Support Multi Rate 1.25-6.25 Gbps
Hot Pluggable SFP+ footprint
1310nm FP transmitter, PIN photo-detector
Transmission distance up to 2km on 9/125 μm SMF
Digital Status monitoring Interface
Duplex LC connector
RoHS compliant and Lead Free
Metal enclosure for lower EMI
Single 3.3V power supply
Power dissipation <1W
Compliant with FC-PI-4 800-Mx-SN-I, SFF-8431 , SFF-8432 and SFF-8472
Operating case temperature:
Standard : -5 to +70℃
Industrial : -40 to +85℃
Applications
High-speed storage area networks
Computer cluster cross-connect
Custom high-speed data pipes
LTE optical repeater application
Description
PPP-316G-02x is a high performance, cost effective modules, which is supporting Multi Rate
1.25-6.25Gbps, and transmission distance up to 2km on SM fiber. The transceiver consists of two
sections: The transmitter section incorporates a 1310nm FP driver and re-timer. The receiver
section consists of a PIN photodiode integrated with a transimpedance preamplifier (TIA). The
module is hot pluggable into the 20-pin connector. The high-speed electrical interface is base on low
voltage logic, with nominal 100 Ohms differential impedance and AC coupled in the module.
