PXC-xx192-06C 10GBASE-LR/LW 60Km CWDM XFP Optical Transceiver

Features

Supports 9.95Gb/s to 11.1Gb/s bit rates

Hot-pluggable XFP footprint

Maximum link length of 60km with SMF

4-Wavelengths Uncooled CWDM DFB laser fromn 1270nm to 1350nm, with Step 20nm

XFP MSA package with duplex LC connector

No reference clock required

Compatible with RoHS

+3.3V power supply

Power dissipation <2.5W

Built-in digital diagnostic functions

Temperature range0°Cto70°C

Applications

SDH STM I-64.1 at 9.953Gbps

10GBASE-LR/LW10GEthernet

1200-SM-LL-L10GFibre Channel

10GE over G.709 at 11.09Gbps

OC192 over FEC at 10.709Gbps

Other optical links, up to 11.1Gbps

Description

Pronets PXC-XX192-06C is compliant with the 10G Small Form-Factor Pluggable (XFP) Multi-Source Agreement (MSA), supporting data-rate of 10.3125Gbps(10GBASE-LR) or 9.953Gbps 10GBASE-LW), and transmission distance up to 60km on SMF.

The transceiver module comprises a transmitter with uncooled CWDM DFB laser and a receiver with a PIN photodiode. Transmitter and receiver are separate within a wide temperature range of0℃to +70℃and offers optimum heat dissipation and excellent electromagnetic shielding thus enabling high port densities for 10 GbE systems.
