PXD-xx192-12C 10GBASE-ZR\ZW\FC 120Km DWDM XFP Optical Transceiver

Features
Wavelength selectable to C-band ITU-T grid wavelengths

Suitable for use in 100GHz channel spacing DWDM systems

XFP MSA Rev 4.5 Compliant

Data rate from 9.95Gbps to 11.3Gbps

Cooled EML and APD receiver

Link length up to 120km (with amplifier)

Low Power Dissipation 3.5W Maximum

XFI and lineside loopback Mode Supported

-5ºC to 70ºC Operating Case Temperature

Diagnostic Performance Monitoring of module temperature,

Supply Voltages, laser bias current, transmit optical power, and receive optical power

RoHS compliant (lead free)

Applications

SONET OC-192&SDH STM 64

Ethernet (10GBASE and 10GBASE with FEC)

DWDM Networks

Description
PRONETS 120km XFP Transceiver exhibits excellent wavelength stability, supporting operation at 100 GHz channel, cost effective module. It is designed for 10G SDH/SONET and 10G Ethernet applications.
The transmitter section incorporates a colded EML laser, and the receiver section consists of a APD photodiode integrated with a TIA, Integrated low power dual CDR with Electronic Dispersion Compensation(EDC). This module can be used to compensate channel impairments caused by either single mode fiber up to 120 km .All modules satisfy class I laser safety requirements. PRONETS XFP transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
