PPP-318G-02C 8.5G Fiber Channel 1310nm 2Km SFP+ Optical Transceiver

 Features

Up to 8.5Gb/s bi-directional data links

Hot Pluggable SFP+ footprint

Built-in digital diagnostic functions

1310nm Fabry-Perot laser transmitter

Duplex LC connector

RoHS compliant and Lead Free

Up to1.4kmat 8Gb/s on 9/125um SMF

Metal enclosure, for lower EMI

Single 3.3V power supply

Operating case temperature: -5℃ to70℃

Applications

Tri Rate 2.125/4.25/8.5Gbs Fibre Channel

Description

Pronets’s PPP-318G-02CSFP+ transceivers are designed for use in Fibre Channel links up to1.4 kmat 8.5 Gb/s data rate. They are compliant with FCPI-4 Rev. 8.00¹ and SFF-8472 Rev 10.2³, and compatible with SFF-8432².
Pronets’s PPP-318G-02CDigital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage. The product is RoHS compliant and lead-free per Directive 2002/95/EC⁵.
