PPP-858G-SRC 8G Fiber Channel 850nm SR 300m SFP+ Optical Transceiver

 Features

Up to 8.5Gb/s bi-directional data links

Hot Pluggable SFP+ footprint

850nm VCSEL transmitter, PIN photo-detector

Transmission distance up to150mOM3 MMF

Digital Status monitoring Interface

Duplex LC connector

RoHS compliant and Lead Free

Metal enclosure for lower EMI

Single 3.3V power supply

Operating case temperature: -5 to70℃

Compliant with FC-PI-4 800-Mx-SN-I, SFF-8431 , SFF-8432 and SFF-8472

Applications

Tri Rate 1.0625/2.125/4.25/8.5Gbs Fiber Channel

Description
PPP-858G-SRC transceivers are designed for using in Fiber Channel links up to 8.5Gb/s data rate over multimode fiber and compliant to SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential.  Data lines are internally AC coupled.  The module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI.
