PPP-318G-LRC Tri Rate 1/2/4/8Gbs Fibre Channel 1310nm 20Km SFP+ Optical Transceiver

 Features

Up to 8.5Gb/s bi-directional data links

Hot Pluggable SFP+ footprint

Built-in digital diagnostic functions

1310nm DFB laser transmitter

Duplex LC connector

RoHS compliant and Lead Free

Up to 20kmon 9/125um SMF

Single 3.3V power supply

Operating case temperature: -5 to70℃

Compliant with FC-PI-4 800-Mx-SN-I, SFF-8431 , SFF-8432 and SFF-8472

Applications

Tri Rate  1.0625/2.125/4.25/8.5Gbs Fibre Channel

Description
Pronets’s PPP-318G-LRC SFP+ transceivers are designed for use in Fibre Channel links up to 8.5 Gb/s data rate and up to20 kmlink length. They are compliant with FCPI-4 Rev. 8.00¹ and
SFF-8472 Rev 10.2³, and compatible with SFF-8432² and applicable portions of SFF-8431 Rev. Pronets’s PPP-318G-LRC Digital diagnostics functions are available via a 2-wire serial interface,
as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage. 3.0⁴. The product is RoHS compliant and lead-free per Directive 2002/95/EC⁵.
